FRAME: XDS X6 Alloy Frame, UDH Compatible
FORK: XDS Suspension Fork, Coil Spring, 80mm Travel, 110x15mm Thru-axle
HANDLEBAR / STEM: Branta Alloy Integrated, w/ Display & Front light, 680mm, Width, 90mm Length, 6 Degree Rise, 15 Degree Backsweep
SEATPOST: XDS 31.6mm Alloy Seatpost , 350mm Length
REAR DERAILLEUR: Shimano Cues RD-U4000, 9-Speed
SHIFTER: Shimano Cues 9-Speed
BRAKES: Branta EC4D Hydraulic E-Bike Brake, w/ Cutoff Switch, 3 Finger Lever, 4 Piston Caliper
CASSETTE: Shimano CS-LG300 11-46T, 9-Speed
CRANKSET: Branta Alloy Crankset, 46T, Narrow-wide Teeth
MOTOR: XDS Mid-drive X800 Motor, 250 Watt Continuous Rated, Power, 470 Watt Peak Power, 95Nm Peak Torque, Dual-sided Torque Sensor
BATTERY: XDS Rechargeable Li-ion Battery, 619Wh, LG Battery Cells, 3A Charger (0-100% 5hr)
LIGHTS: Integrated F+R Lights (+ Brake Lights)
SPEED: Pedal-assist and Throttle, Class 2 20mph (Unlock to Class 3 via the X-Lab Bikes Mobile App)
RANGE: Ride up to 75 miles on a Single Charge
TESTING AND COMPLIANCE: UL2271 and UL2849 Certified, Ingress Ratings: Complete Bike IP54, Battery IPX7, Motor and Other Electronics IPX6
LOAD CAPACITY: Max Load 330 lbs (150 kg)
CONNECTIVITY: Apple Find My Anti-Theft Technology, Bluetooth, OTA Updates
ROTORS: Branta PN28, F:180mm R:180mm
CHAIN: KMC E-GLIDE-S
WHEELSET: Branta Alloy E-Bike Wheelset
TIRES: CST CTC-06, 27.5’’x2.4, 30TPI, w/ Reflective Stripe, Max Tire Clearance: 2.4"
SADDLE: Branta C301
PHONE HOLDER: Quad Lock Mount
REAR RACK: MIK-HD Rack
WEIGHT: 24.76 kg / 54.58 lbs (Size L)
SIZE OPTIONS: M / L
