Where endurance meets excellence. Featuring BMC carbon frame craftsmanship, full integration with the trusted Shimano Ultegra - every road is yours to master.
-
Frame:
Roadmachine Carbon with Tuned Compliance Concept Endurance | ICS Technology Stealth Cable Routing | Fender Mounts | Integrated Downtube Storage | Stealth Dropout Design | 12 x 142mm Thru-Axle
-
Fork:
Roadmachine Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle | 50mm offset Size 47-51 | 45mm offset Size 54-61
Cockpit
-
Stem:
BMC RSM 01 | Integrated Cockpit System Technology
-
Handlebar:
BMC HB D4 03, 0, 12 | Alloy 6061 | Endurance Geometry | 125mm drop, 70mm reach, 12° flare
Seat
-
Seatpost:
Roadmachine Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
-
Saddle:
Selle Italia Model X Superflow | FeC Alloy Rail | 145mm
Drivetrain
-
Crankset:
SHIMANO Ultegra (FC-R8100)
-
Chainrings:
50-34T
-
Cassette:
SHIMANO Ultegra (CS-R8101)
-
Cassette Size:
11-34T
-
Chain:
SHIMANO CN-M8100
-
Front Derailleur:
SHIMANO Ultegra Di2 (FD-R8150)
-
Rear Derailleur:
SHIMANO Ultegra Di2 (RD-R8150)
-
Shifters:
SHIMANO Ultegra Di2 (ST-R8170)
-
Gears:
2 x 12
-
Bottom Bracket:
SHIMANO Ultegra Press-Fit Bottom Bracket (SM-BB72-41B)
Brakes
-
Brake Levers / Calipers:
SHIMANO Ultegra (BR-R8170)
-
Rotors:
SHIMANO Ultegra (RT-CL800)
-
Rotor Size (F/R):
160 / 160mm
Wheels
-
Rims:
AR 27 | Tubeless Ready | 27mm [or] DT SWISS C1850 Spline
-
Hubs (F/R):
AR 27: CL-712 & RXC-142 Center Lock [or] C1850: DT Swiss Spline
-
Tires:
Vittoria Rubino V TLR | Tubeless | 32mm
-
Tubeless Information:
Tubeless Rim | Tubeless Tires
Additional Information
-
Tire Clearance:
up to "40mm measured" (frameset clearance) but limited to "34mm measured" by the front derailleur
